3539 08 13 — Pneumatic Push-In Fittings – LF 3000® — Elbow 90° — 8mm, G1/4

Name: J&J Air Systems
Price range: $$

£9.82 exc. VAT; £11.78 inc. VAT

3539 08 13 — The LF 3000® push-in fittings range includes banjo, oscillating, and modular multiport functions offering multiple configurations. Robust, lightweight, and compact thus connectors allow you to optimize the design of your pneumatic equipment.

Available to order - usually dispatched within 1 week (Manufacturer Dependant)

SKU: 3539 08 13 Category: Fittings Accessories

Description
Additional information

Description

The 3539 08 13 is a Pneumatic Push-In Fittings – LF 3000® (Elbow 90°, 8mm, G1/4), supplied from UK stock by J&J Air Systems. It is rated to an operating temperature range of -20°C to 80°C.

Specification

Part number: 3539 08 13
Size / variant: Elbow 90°, 8mm, G1/4
Operating temperature: -20°C to 80°C
Suitable for: Air (Compressed Air) | Other Fluids: Please Consult Us
Applications: Vacuum | Textile | Pneumatics | Robotics | Automotive | Packaging
Weight: 0.013 kg

Need technical advice, availability or volume pricing? Call 0800 0278 442 or email [email protected].

About this range

The LF 3000® push-in fittings range includes banjo, oscillating and modular multiport functions offering multiple configurations. Robust, lightweight, and compact thus connectors allow you to optimize the design of your pneumatic equipment.
Features/Benefits:
•Reliability
•100% leak-tested in production
•Date coding to guarantee quality and traceability
•Durability
•Conforms to ISO 14743
•Tried-and-tested longevity technology
•High number of pressure cycles
•No pumping effects
•Flexibility
•Compactness for space saving
•Multiple shapes and configurations for more modularity
•Sustainability
•ROHS and REACH compliant
•Eco-friendly thanks to full flow for efficiency
•Low carbon-printing – Made in Europe
Markets:
•Automation
•Industrial
•Food processing
Applications:
•Packaging manufacturing,
•Robotic,
•In-plant automotive,
•Pneumatics,
•Solenoid valves,
•Pneumatic cylinders
•Pneumatic Machinery Equipment
•Low Pressure Compressed Air Conveying
•Vacuum systems
•Semiconductor machinery
•Textile machinery
•Cabinets/Panels
Technologies:
•Push-In Fittings
•Push-to-Connect Fittings
•Pneumatic Fittings
•Instant Fittings
•Quick Fittings
•Connectors
•Swivel Fittings
•Orientable Fittings
•Modular Fittings
•Multi-Connectors
•Modular Plug-In Connectors
•Self-Sealing Fittings
•Connectors
Technical Characteristics:
•Fluids: compressed air, neutral gas, other fluids: please contact us
•Materials: Technical polymer, nickel-plated brass, NBR
•Pressure: Vacuum to 20 bar
•Temperature: -20°C to +80°C
•Ø Metric: 3mm to 16 mm
•Ø Inch: 1/8″ to 1/2″
Regulations:
•ISO 14743
•PED
•RoHS
•REACH

Additional information

Weight	0.005 kg
Body Material	Nickel-plated, Technical Polymer \| Brass
Configuration	Tube to Tube
Connection 1 Size	8 mm Tube O.D.
Connection 1 Type	Tube
Connection 2 Size	G 1/4 inch Thread
Product Series	LF 3000®
Product Style	Banjo
Product Type	Pneumatic Push-In Fittings – LF 3000®
Seal Material	NBR
Shape	Elbow 90°
Application	Vacuum \| Textile \| Pneumatics \| Robotics \| Automotive \| Packaging
Brand	Legris \| Parker
Division	Low Pressure Connectors Europe Division \| Low Pressure Connectors Europe Division
For Fluid Type	Air (Compressed Air) \| Other Fluids: Please Consult Us
Gripping Ring Material	Stainless Steel
Industry	Semiconductor \| Transportation \| Chemicals Processing \| Industrial Manufacturing Equipment \| Power Generation \| Electronics \| Off-road Machinery \| Renewable Energy \| Industrial Processing
Maximum Operating Temperature	80 °C
Minimum Operating Temperature	-20 °C
Quantity per Box	10
Technology	Fluid & Gas Handling
Vacuum Pressure Rating	755 mm-Hg
Weight	0.013 kg
